DJYP2VP2 LAN Communication Cable

DJYP2VP2 LAN Communication Cable

Product Description

The DJYP2VP2 LAN Communication Cable represents a purpose-built, high-performance data transmission solution engineered specifically to overcome the electromagnetic challenges inherent in industrial automation and process control environments. Designed as a robust alternative to standard office-grade Ethernet cables, this cable features a sophisticated layered shielding architecture that combines both individual pair-level and overall cable-level protection. Each twisted pair is independently shielded with aluminum foil, providing critical protection against crosstalk (internal interference), while an overall overlapping copper tape shield encases all pairs, creating a comprehensive barrier against external electromagnetic interference (EMI) and radio frequency interference (RFI). This dual-shield design ensures data integrity in the presence of heavy machinery, variable frequency drives (VFDs), and high-power electrical systems, making it a cornerstone for reliable digital infrastructure in modern industrial settings. The cable employs polyethylene (PE) insulation for stable high-frequency performance and is protected by a durable, low-smoke, zero-halogen (LSZH) or polyvinyl chloride (PVC) outer sheath for mechanical and environmental resilience.

The technical distinction of the Ruiyang DJYP2VP2 cable lies in its defense-in-depth approach to signal protection. The individually foil-shielded twisted pairs maintain precise characteristic impedance and minimize alien crosstalk, which is essential for high-speed data protocols. The overall copper tape shield, typically with a drain wire, provides nearly 100% coverage and offers superior low-frequency magnetic field attenuation compared to braided shields. This combination is particularly effective against the broad-spectrum noise found in industrial plants, from the low-frequency hum of transformers to the high-frequency switching noise of inverters. The PE insulation ensures low dielectric loss and stable propagation velocity, critical for maintaining signal timing in protocols like Profinet, Ethernet/IP, or Modbus TCP/IP. The outer sheath is engineered for industrial duty, offering resistance to oils, acids, abrasion, and UV exposure, ensuring physical protection in cable trays, conduits, or direct burial applications.

Detailed information:

Conductor Material: Copper

Jacket: PVC

Shielding Type: Coppe wire braid, copper tape or alumunium foil

Standard: IEC60502, IEC60227, BS5308

Voltage: 300/500V

Armour: Steel wire armoured SWA

Color: Black, blue or red

Company profile

Production process

Applications

Product packaging

Our Services

1. Quickly and professional response.

2. China manufacturer with 8 years experience.

3. Excellent quality with reasonable price.

4. Sufficient support for our tendering representatives.

5. OEM service available based on official & legal authorization.

6. Strict quality control system.

7. Faster lead time than our competitors.

8. Cable solutions to your particular requirements.

9. Free sample is available with economic express fee.

10. 12 months quality guarantee after delivery.

FAQ

Q1: What kind of guarantee do you provide?

A1: 1. 100% high quality, all failed parts get free warranty within 30 days after received.

2. Accept 10 years warranty upon customer requirement.

3. Repairs parts are available within 10years; We will inform the EOL products to you from time to time.

Q2: What if the cable which we need have some differences on specifications from yours?

A2: Any difference, we can design and produce according to your requests, which include cable, color, material, processing requirement etc.

Q3: How can I get a sample to check your quality?

A3: After price confirmation, you can require for sample to check our quality. Sample is free, but the freight charge should be paid.
