Product Description

The Elbow Connector, also known as an elbow terminator or separable connector, is a compact and fully insulated cable accessory designed for medium-voltage distribution systems. Its unique 90-degree angled design allows for easy connection and disconnection in confined spaces, such as switchgear, transformers, and ring main units (RMUs). The connector features a built-in load-break or fault-make capability, enabling safe hot-stick operation under load conditions without de-energizing the system. With a robust silicone rubber insulation and shielded construction, it provides reliable protection against electrical stress, moisture, UV radiation, and environmental contaminants, making it ideal for indoor and outdoor applications.

Engineered for versatility and safety, the elbow connector integrates a precision-engineered contact system that ensures low-resistance connections and arc-free operation. Its epoxy-free design and tested reliability offers full compatibility with equipment from major manufacturers. The connector's lightweight yet durable construction simplifies installation and reduces maintenance needs, while its visible break point enhances operational safety. Widely used in utility networks, industrial plants, and renewable energy projects, the elbow connector delivers a cost-effective and efficient solution for transitioning between cables and equipment.

Product Display

• IEC European Cable Accessory Series 15-36kV Shielded Front/rear Connectors

Shielded front/rear connectors are used in cable branch boxes, RMU, box substation, etc. to ensure that this product can realize multi-branch power supply. It is used for Φ46/ Φ56 /91.5/M16 casing fully sealed connection, and is suitable for cable cross-section 25~400mm².

• 15-24kV Elbow/Inline Connectors

Elbow and inline connectors are suitable for 24kV and 15kV electrical systems, for use on Euro RMU.

• EEE American Cable Accessory Series 15kV Elbow Plugs

American Elbow Heads are used for high voltage electrical connections to American box transformers, RMU, cable branch boxes, buried transformers and other electrical equipment. Interface composite IEEE386、200A bushing design standard.

• 15kV PT plug


The PT plug is used to provide the fully insulated, fully shielded, and fully sealed connection for high voltage end of transducer which provides power supply to an electric operating mechanism or a metering protection device. The primary winding has a fuse protection device and is equipped with a cable plug socket; the bushing socket size conforms to the 25kV 200A bushing size standard of IEEE Std386.
